SDI⇌HDMI Cross
Cross Converter
| Model Name | SDI⇌HDMI Cross |
| Description | SDI or HDMI to HDMI and SDI Cross Converter |
| Feature |
Multi-Standard Support ( 3G / HD / SD-SDI ) High Quality Digital Direct Conversion Auto Source Format Detection Power Amplified SDI Loop Out 3G-SDI Level A/B Support Input : Level B Dual Link / Dual Stream Support SDI to HDMI and HDMI to SDI at Same Time |
| Input Interface |
Video HDMI×1 SDI×1 |
| Output Interface |
Converted Video HDMI×1 SDI×2 |
| Supported Video Input Format |
HDMI 1920×1080p@60/50fps 1920×1080p@30/25/24fps 1920×1080i@60/50fps 1280×720p@60/50fps 720×480i@60fps 720×576i@50fps SDI 3G-SDI 1920×1080p@60/50fps HD-SDI 1920×1080p@30/25/24fps 1920×1080i@60/50fps 1280×720p@60/50fps SD-SDI 720×480i@60fps 720×576i@50fps |
| Supported Video Output Format |
HDMI : As input SDI or HDMI format SDI : As input SDI or HDMI format |
| GENLOCK Frame Lock Mode | N/A |
| Audio Input Format |
SDI : Up to 8 channels, 24bit, 48KHz HDMI : Up to 8 channels, 24bit, 192KHz |
| Audio Output Format |
SDI : Up to 8 channels, 24bit, 48KHz HDMI : Up to 8 channels, 24bit, 48KHz |
| Plug & Play | ✓ |
| DC In | 7.5V ~ 15V |
| Dimension | L:153mm×W:70.6mm×H:26mm |
