HDMI2.0 to Copper
Transfer 4K Video via Cat.6A Cable
![HDMI2.0 to Copper](/keeper/images/Q29udmVydGVy/RXh0ZW5kZXI/NEs/MTBH/SERNSTIuMCB0byBDb3BwZXIgQ292ZXI.jpg)
Model Name | HDMI2.0 to Copper |
Description | HDMI 2.0 to 10G Copper Converter |
Feature |
Compact Design Auto Source Format Detection |
Input Interface |
Video HDMI 2.0×1 |
Output Interface |
Converted Video RJ45×1(For AVXT output |
Supported Video Input Format |
HDMI 2.0 4096x2160p@60/50fps 4096x2160p@30/25/24fps 3840x2160p@60/50fps 3840x2160p@30/25/24fps 1920×1080p@60/50fps 1920×1080p@30/25/24fps 1920×1080i@60/50fps 1280×720p@60/50fps 1280×1024p@60fps 1280×960p@60fps 1024×768p@60fps 800×600p@60fps 640×480p@60fps 720×480p@60fps 720×576p@50fps 720×480i@60fps 720×576i@50fps |
Supported Video Output Format |
RJ45 ( Converted ) Network Packet for Video Transfer |
GENLOCK Frame Lock Mode | N/A |
Audio Input Format | HDMI : Up to 8 Channels, 24bit, 192KHz |
Audio Output Format | AVXT : Up to 8 Channels, 24bit, 192KHz |
Plug & Play | ✓ |
DC In | 7.5V ~ 15V |
Dimension |
L:106mm×W:58mm×H:26mm |
