SC6D0N4 SDI

4CH SDI 1080P60 ENCODER+DECODER+SWITCH

SC6D0N4 SDI
Slogan 4CH SDI 1080P60 ENCODER+DECODER+SWITCH
Model Name SC6D0N4 SDI
Max. FPS 1920×1080p@300fps(4 SDI + 1 PGM Channels)
Recording Mode Hardware Compression
5G Support CPU
Dual-core ARM Cortex A9@1.1 GHz
32 KB L1 I-cache, 32 KB L1 D-cache
256 KB L2 cache
NEON and FPU
A/V Input Interfaces Video
4×SDI
Audio
4×3.5mm
A/V Output Interface Video
1×HDMI ( Multiview / PGM )
1×SDI ( PGM )
Audio
1×3.5mm
Video Feature H.264/AVC, Baseline/Main/High Profile
Configurable Bit Rate Up to 64Mbps

Support input resolutions
1920×1080 ( P60/P50/P30/P25/P24/i60/i50 )
1280×720 ( P60/P50)

Support output resolutions
Resize Range from 160×120 to 1920×1080 ( P60 )
Audio Feature AAC-LC
Configurable bit rate range from 32Kbps to 384Kbps
Sample rate : 48KHz, 16bit
Network Feature 1×RJ45 for 10/100/1000Mbps Ethernet
Expandable internet interface on board
DHCP client
Support Streaming protocol NDI Support ( Separate License with NDI Required )
RTSP over UDP/TCP/Multicast/HTTP
RTMP ( Publish )
TS over IP
HLS
Misc. Features Web UI for system configuration
Firmware upgradable
LED indicator
Status with Power Recycle
2×USB2.0 (For Keyboard and mouse usage)
1×USB3.0 (For external storage usage)
1×RS232 + 1×RS485/RS232
Main function switch
Record
Snapshot
Stream
PGM mode switch
Full screen
Quadview
Picture by picture
Picture in picture
PGM Loop
Full screen switch
Channel 1
Channel 2
Channel 3
Channel 4
Record Format MP4 / TS / MOV
Power Supply DC input : 12V / 2A
