SC6T0N4 HDMI2.0 AI+
4CH HDMI2.0 4KP60 ENCODER+DECODER+SWITCH+AI
| Model Name | SC6T0N4 HDMI2.0 AI+ |
| Max. FPS | 4096×2160p@60/50fps |
| CPU | 11th Gen Intel® Core™ i7 1165G7 ( 2.8GHz ) |
| 5G Support |
LTE Cat20 ( Option ) LTE FDD Supported LTE TDD Supported Sub-6 ( Option ) SA Supported Non-SA Supported ** Optional by Customer Request |
| A/V Input Interfaces |
Video 4×HDMI2.0 Audio 4×HDMI Embedded Digital Audio ( LPCM ) 1×3.5mm Line/MIC in |
| A/V Output Interface |
Video 2×HDMI2.0 ( Multiview / PGM ) Audio 2×HDMI Embedded Digital Audio ( LPCM ) 1×3.5mm Line out |
| Video Feature |
Support Input / Output Resolutions 4096×2160p@60/50fps 3840×2160p@60/50fps 4096×2160p@30/25/24fps 3840×2160p@30/25/24fps 1920×1080p@60/50fps 1920×1080p@30/25/24fps 1920×1080i@60/50fps 1280×720p@60/50fps 1280×1024p@60fps 1280×960p@60fps 1024×768p@60fps 800×600p@60fps 640×480p@60fps 720×480p@60fps 720×576p@50fps 720×480i@60fps 720×576i@50fps |
| Video Encode |
Support Resolutions 4096×2160p@60/50fps 3840×2160p@60/50fps 4096×2160p@30/25/24fps 3840×2160p@30/25/24fps 1920×1080p@60/50fps 1920×1080p@30/25/24fps 1920×1080i@60/50fps 1280×720p@60/50fps 1280×1024p@60fps 1280×960p@60fps 1024×768p@60fps 800×600p@60fps 640×480p@60fps 720×480p@60fps 720×576p@50fps 720×480i@60fps 720×576i@50fps |
| Audio Feature |
Configurable bit Rate Range from 32Kbps to 384Kbps Sample Rate : 48KHz, 16bit, Stereo |
| Network Feature |
2×RJ45 for 10/100/1000Mbps Ethernet DHCP Client **Wifi ( Option ) : **802.11b/g/n **802.11ac ** Optional by Customer Request |
| Support Streaming protocol |
NDI Support ( Separate License with NDI Required ) RTSP over UDP/TCP/Multicast/HTTP RTMP Public ( web Portal ) **TS over IP **HLS ** Optional by Customer Request |
| Misc. Features |
Firmware Upgradable LED Indicator 2×USB3.0 2×USB2.0 Bluetooth Supported ( Option ) |
| PGM mode switch |
PGM Mode Switch Full Screen : Quadview Picture by Picture Picture in Picture PGM Loop Full Screen Switch : Channel 1 Channel 2 Channel 3 Channel 4 |
| Support Record Device |
External USB3.0 HDD Internal SATA 2.5" HDD ✻ HDD Not Included at SC6T0 |
| SDK Support |
YUAN QCAP Video Capture SDK YUAN QDEEP AI Algorithm SDK Intel® Distribution of OpenVINO™ toolkit |
| AI Features |
Face Tracking Background Effect Extracting Handwriting ePTZ Customizable Video AI Functions Upon Request : QDEEP AI SDK Integrated Multiple Algorithms and Deep-Learning Models in Various Fields of Applications. |
| Record Format | N/C |
| Power Supply | DC input : 19V |
