SC6F0N1 HDMI2.0 PRO

1CH HDMI2.0 4KP60 ENCODER+DECODER

SC6F0N1 HDMI2.0 PRO
Model Name SC6F0N1 HDMI2.0 PRO
Max. FPS 4096×2160p@60/50fps
Recording Mode Hardware Compression
CPU N/C
5G Support N/A
A/V Input Interfaces Video
1×HDMI2.0

Audio
1×3.5mm stereo analog audio
A/V Output Interface Video
1×HDMI2.0
1×HDMI2.0 ( Loop-through )

Audio
1×3.5mm stereo analog audio
Video Feature H.265/H.264 Hardware Compression

Support resolutions
4096×2160p@60/50fps
4096×2160p@30/25/24fps
3840×2160p@60/50fps
3840×2160p@30/25/24fps
1920×1080p@60/50fps
1920×1080p@30/25/24fps
1280×720p@60/50fps
1280×720p@30/25/24fps
Video Encode N/C
Audio Feature AAC-LC
Configurable bit rate range from 32Kbps to 384Kbps
Sample rate : 48KHz, 16bit, Stereo
Network Feature 1×RJ45 for 10/100/1000Mbps Ethernet
Wifi:
802.11b/g/n for Option
Wireless Display ( Option ):
Frequency Band: 60GHz
Bandwidth: 2.16GHz
Modulation: 16QAM, QPSK
Transmission Power: Maximum 29dBm
Sensitivity: -72dBm@MCS1
Delay: 100m Seconds
Support Streaming protocol NDI HX 3 Tx/Rx Support ( Separate License with NDI Required )
Full NDI Tx/Rx Support ( Separate License with NDI Required )
TS Over UDP ( Unicast & Multicast )
RTSP Over HTTP/TCP/UDP ( RTSP Elementary Stream )
RTMP ( Publish )
HLS
SRT
Misc. Features Web UI for system configuration
Firmware upgradable
LED indicator
Status with Power Recycle
Ref-In and Ref-Loop for Genlock ( Option )
1×USB3.0
2×USB2.0
1×RS232 + 1×RS485
PGM mode switch N/C
Support Record Device N/C
SDK Support N/C
AI Features N/C
Record Format MP4 / TS / MOV
Power Supply DC input : 12V / 2A
Support POE input
