SC6E0N1 AIO

1CH SDI+HDMI 1080P60 ENCODER+DECODER

SC6E0N1 AIO
Model Name SC6E0N1 AIO
Max. FPS 1920×1080p@60/50fps
Recording Mode Hardware Compression
CPU N/C
5G Support N/A
A/V Input Interfaces Video
1×BNC for 3G/HD/SD-SDI
3×BNC for YPbPr/CVBS/S-Video
1×DVI-I for DVI-D/HDMI and DVI-A/VGA
1×HDMI
Audio
2×RCA for Analog L/R Audio
SDI/HDMI/DVI-D Embedded Audio
1×3.5 mm Phone Jack
A/V Output Interface Video
1×HDMI
Video Feature H.265/H.264/AVC, Baseline/Main/High Profile

Support input / output resolutions
1920×1080p@60/50fps
1920×1080p@30/25/24fps
1920×1080i@60/50fps
1280×720p@60/50fps
1280×1024p@60fps
1280×960p@60fps
1024×768p@60fps
800×600p@60fps
640×480p@60fps
720×480p@60fps
720×576p@50fps
720×480i@60fps
720×576i@50fps
Video Encode N/C
Audio Feature Input Audio Stream:
AAC
Network Feature 1×RJ45 for 10/100/1000Mbps Ethernet
DHCP Client
Support Streaming protocol NDI Support ( Separate License with NDI Required )
Dante AV-H ( Separate License with Dante AV-H Required )
RTSP over UDP/TCP/Multicast/HTTP
RTMP ( Publish )
TS over IP
HLS
Misc. Features RS485
1×USB 3.0 Host for USB Storage
2×USB 2.0 (For Keyboard and mouse usage)
Web UI for System Configuration
Firmware Upgradable
LED Indicator
PGM mode switch N/C
Support Record Device N/C
SDK Support N/C
AI Features N/C
Record Format MP4 / TS / MOV
Power Supply DC input : 12V / 2A
